TL LED Pod

ThinkLite LED Pod is a direct replacement for up to 400W metal halide and high-pressure sodium lamps, and delivers equivalent light to a traditional HID lamp, while reducing total energy output. The lifespan is rated and guaranteed at 50,000 hours, while achieving over 131 lumens per watt throughout its lifespan. The Pod is supplied with a customized bracket that fi ts in the existing fi xture being retrofi tted. The ThinkLite LED Pod is highly recommended for use in parking garages, tennis courts, warehouses and other high bay applications.


Features of TL LED Pod:


• Reduced energy consumption by up to 70%
• Vibration and impact resistant
• Longer lifespan (50,000 hours)
• 5 year warranty
• No harmful UV rays
• Instant on / off
• Copper infused PCB board
• IP65 Frictionless Fan
• High Density Aluminum/Steel Alloy Heat Sink

TECHNICAL SPECIFICATION

Wattage Range : 120W / 150W / 200W
Voltage : 90V - 277V
ProjOperational Frequency : 50Hz - 60Hz
Base Type : Custom Bracket (E27, E40)
Efficacy : 131 LM/W
Temperature Range : -35°C to 55°C
CRI : 93+
Lumen Depreciation : 95% at 50,000 hours
Download : TL LED Pod_1.pdf Download : TL LED Pod_2.pdf Download : TL LED Pod_3.pdf
